Rotary Wire Cutting and Stripping Machine
Rotary Wire Cutting and Stripping Machine
Rotary Wire Cutting and Stripping Machine
Rotary Wire Cutting and Stripping Machine
Rotary Wire Cutting and Stripping Machine
Rotary Wire Cutting and Stripping Machine

Rotary Wire Cutting and Stripping MachineRotary Wire Cutting and Stripping Machine

Our rotary wire cutting and stripping machine is designed to revolutionize your wire processing operations. It delivers unparalleled precision and efficiency in wire cutting and stripping tasks.Whether you're working with small-scale wire processing or handling large volumes, this machine is designed to meet your requirements with utmost professionalism.

Model:
  • YH-612X
Brand:
  • Yuanhan
Inquire
Share to:
Features
Specifications

○ Equipped with advanced rotary cutting technology, this machine ensures clean and accurate cuts every time, eliminating the need for manual trimming and reducing the risk of wire damage. Its high-speed stripping capabilities allow for swift and seamless removal of insulation, saving you valuable time and effort.

○ With a user-friendly interface and intuitive controls, operating our Rotary Wire Cutting and Stripping Machine is a breeze. Its robust construction guarantees durability and longevity, making it a reliable asset for your wire processing needs.

○ Our machine boasts a range of features that enhance productivity and convenience. The adjustable cutting and stripping parameters enable customization to suit various wire sizes and insulation types, ensuring optimal results for every application. Additionally, the integrated safety mechanisms prioritize operator well-being, minimizing the risk of accidents or injuries.

○ Optional: MES system, Internet of Things system, fixed-point coding function, middle stripping function, external auxiliary equipment alarm.

Model

YH-612X

Display method

7-inch human-machine interface

Function

rotary fixed-length cutting and stripping

Wire type

single-core wire, multi-core wire, power cable, multi-layer wire, shielded wire, new energy charging cable, etc.

Processing range

6-120mm²

Cutting length

1mm-999999.99mm

Cutting tolerance

Within 0.002*L (L=cutting length)

Stripping length

side A full stripping: 1 - 300mm; side A half stripping: 1-1000mm
side B full stripping: 1- 150mm; side B half stripping: 1-500mm

Max. diameter of guiding pipe

Φ24

Wheel lifting method

Stepper motor lifting wheel

Tool material

High quality imported high speed steel

Productivity

800-1000pcs/hour (depending on the length and size of the cable)

Drive mode

24-wheel drive (feeding stepper motor, tool holder servo motor); servo feeding optional

Wire delivery method

Belt feeding, no embossing or scratches on the cable. (With peeling and pressing function)

Lifting operation mode

Digitally adjustable pressure wheel height

Power supply

AC220V 50/60Hz; 110V 50/60Hz optional

Air source

0.5-0.8Mpa clean air source

Dimensions (length*width*height)

1400*720*1460mm

Net weight

300KG
